Additional information
| Dimensions | 330.2 × 330.2 × 35.6 mm |
|---|---|
| Vendor | AccelTex Solutions |
| Country of Origin | China |
| Antenna Gain | 8/8/8 dBi |
| Beamwidth - Horizontal | 115°/110°/110° |
| Beamwidth - Vertical | 50°/25°/25° |
| Cable Length | 910mm |
| Cable Type | ATS-195 |
| Connector Type | N-Style |
| Frequency Rating | 2.4-2.48/5.15-5.85/6-7.125 GHz |
| Antenna Type | Patch Antenna |
| Impedance | 50 Ohms |
| Indoor/Outdoor | Indoor/Outdoor |
| Input Power - Max | 50 W per port |
| Installation Type | Flush Mount to Wall/Ceiling or Articulating Mount (included) |
| Isolation Loss | ˃30 dB |
| Radome Material | ABS |
| Number of Leads | 8 |
| Operating Temperature | -40 to 70 °C |
| Polarisation | 4 Horizontal, 4 Vertical |
| Wi-Fi Standard | 802.11ax (Wi-Fi 6) |
| Voltage Ratio | ≤ 2.5 |
| Windage | 134 mph (216 km/h) |
