| Dimensions | 440 × 440 × 44 mm |
|---|---|
| Vendor | Cambium Networks |
| Switch Class | Layer 3 |
| Gigabit Ethernet Ports | 8 |
| Multi-Gigabit Ethernet Ports | 6 |
| SFP+ Ports | 2 |
| RJ45 Console Port | Yes |
| Form Factor | 1U |
| PoE | 802.3af/at/bt |
| Total PoE Budget (W) | 240 |
| PoE Capable Ports | 14 |
| Switching Capacity | 86Gbps |
| Packet Forwarding Rate (Mpps) | 120 |
| MAC Address Table | 16K |
| Flash Storage | 128MB |
| SDRAM | 512MB |
| Full-load Power Consumption (W) | 26.76 |
The EX3028R-P series offers 24 10/100/1000 Mbps access ports with 4 SFP+ (10 Gbps) fiber uplink ports. The EX3028R-P switch also offers dual removable power supplies and features up to 60W of PoE per port.
The cnMatrix series of fully managed switches delivers full Layer 2 and Layer 3 capabilities with enhanced access security. Depending on the model, the cnMatrix EX2000 series offers flexibility with SFP+ (10 Gbps) or SFP (1 Gbps) uplink ports. These switches come with a 5-Year Limited Lifetime Warranty.
cnMatrix TX provides Wireless ISP operators a non-blocking, fully managed, enterprise grade L2/L3 switch portfolio, flexible and intelligent PoE and Cambium synchronization in a single box solution that is easy to install and manage while improving network performance.
Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.
The EX3052R-P series offers 48 10/100/1000 Mbps access ports with 4 SFP+ (10 Gbps) fiber uplink ports. The EX3052R-P switch also offers dual removable power supplies and features up to 60W of PoE per port.
cnMatrix TX provides Wireless ISP operators a non-blocking, fully managed, enterprise grade L2/L3 switch portfolio, flexible and intelligent PoE and Cambium synchronization in a single box solution that is easy to install and manage while improving network performance.
Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.
cnMatrix TX provides Wireless ISP operators a non-blocking, fully managed, enterprise grade L2/L3 switch portfolio, flexible and intelligent PoE and Cambium synchronization in a single box solution that is easy to install and manage while improving network performance.
Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.
The cnMatrix series of fully managed switches delivers full Layer 2 and Layer 3 capabilities with enhanced access security. Depending on the model, the cnMatrix EX2000 series offers flexibility with SFP+ (10 Gbps) or SFP (1 Gbps) uplink ports. These switches come with a 5-Year Limited Lifetime Warranty.
The EX3028R-P series offers 24 10/100/1000 Mbps access ports with 4 SFP+ (10 Gbps) fiber uplink ports. The EX3028R-P switch also offers dual removable power supplies and features up to 60W of PoE per port.
