cnMatrix™ EX2028-P switches simplify network deployment and operation. When deployed with cnPilot™ WLAN access points and the cnMaestro™ management system, network operators have an affordable, feature rich, high quality unified wired/ wireless enterprise grade network. Improve performance, security and end user satisfaction while reducing costs with cnMatrix EX2028-P.
| Dimensions | 440 × 330 × 44 mm |
|---|---|
| Vendor | Cambium Networks |
| Switch Class | Layer 3 |
| Gigabit Ethernet Ports | 24 |
| SFP+ Ports | 4 |
| RJ45 Console Port | Yes |
| Form Factor | 1U |
| PoE | 802.3af/at |
| Total PoE Budget (W) | 400 |
| PoE Capable Ports | 8 |
| Switching Capacity | 128Gbps |
| Packet Forwarding Rate (Mpps) | 120 |
| MAC Address Table | 16K |
| Flash Storage | 128MB |
| SDRAM | 512MB |
| Full-load Power Consumption (W) | 25.1 |
cnMatrix™ EX2028 switch simplifies network deployment and operation. When deployed with cnPilot™ WLAN access points and the cnMaestro™ management system, network operators have an affordable, feature rich, high quality unified wired/ wireless enterprise grade network. Improve performance, security and end user satisfaction while reducing costs with cnMatrix EX2028.
TSW010 Ethernet switch offers the most affordable way to extend network connectivity to multiple Ethernet devices. Five 10/100 Mbps Ethernet ports ensure stable and reliable connectivity, sufficient for most industrial applications where high throughput is not required.
cnMatrix™ EX2028 switch simplifies network deployment and operation. When deployed with cnPilot™ WLAN access points and the cnMaestro™ management system, network operators have an affordable, feature rich, high quality unified wired/ wireless enterprise grade network. Improve performance, security and end user satisfaction while reducing costs with cnMatrix EX2028.
The TSW040 is an unmanaged 8-port PoE+ switch by Teltonika, featuring eight RJ45 ports with a total power budget of 240 W, or up to 30 W per port. This compact and rugged 8-port switch also features a 2-pin power input and an integrated DIN rail for easy mounting, making it ideal for industrial applications. The TSW040 has a wide voltage range of 7-57 VDC and a PoE-out voltage range of 44-57 VDC.
